固体火箭冲压发动机导弹气动外形设计与试验研究

刘远, 程养民, 李晓晖, 闫宝任

刘远, 程养民, 李晓晖, 闫宝任. 固体火箭冲压发动机导弹气动外形设计与试验研究[J]. 空气动力学学报, 2016, 34(6): 790-796. DOI: 10.7638/kqdlxxb-2014.0043
引用本文: 刘远, 程养民, 李晓晖, 闫宝任. 固体火箭冲压发动机导弹气动外形设计与试验研究[J]. 空气动力学学报, 2016, 34(6): 790-796. DOI: 10.7638/kqdlxxb-2014.0043
shu
Liu Yuan, Cheng Yangmin, Li Xiaohui, Yan Baoren. Aerodynamic design and experimental study of a missile propelled by solid rocket ramjet[J]. ACTA AERODYNAMICA SINICA, 2016, 34(6): 790-796. DOI: 10.7638/kqdlxxb-2014.0043
Citation: Liu Yuan, Cheng Yangmin, Li Xiaohui, Yan Baoren. Aerodynamic design and experimental study of a missile propelled by solid rocket ramjet[J]. ACTA AERODYNAMICA SINICA, 2016, 34(6): 790-796. DOI: 10.7638/kqdlxxb-2014.0043
shu

固体火箭冲压发动机导弹气动外形设计与试验研究

  • 西安航天动力技术研究所, 陕西 西安 710025

详细信息
    作者简介:

    刘远(1991-),男,硕士研究生,主要研究方向:导弹武器系统工程设计.E-mail:steedliuy@163.com

  • 中图分类号: V211.7;E927

Aerodynamic design and experimental study of a missile propelled by solid rocket ramjet

  • Xi'an Institute of Aerospace Propulsion Technology, Xi'an 710025, China

摘要

    摘要
  • 摘要: 某固体火箭冲压发动机导弹存在着航程阻力大、静稳定性差、平衡攻角偏大、舵效偏高等一系列问题。根据导弹的基准外形，结合相关理论，对影响导弹气动性能的关键部件进行了分析与比较研究，并对外形进行改进，建立了一系列差异化几何模型。用FLUENT软件，对导弹在不同攻角条件下外流场进行数值计算，得出了各模型的轴向力系数、法向力系数和俯仰力矩系数随攻角的变化规律以及表面的压力分布情况。计算结果表明，就设计目标考虑，采用改进后的大进气道、小弹翼、舵面边条、后掠舵面和水平尾翼布局的模型性能最优。为进一步研究该最优布局下各关键部件对导弹气动性能产生的影响，进行了组拆选型风洞试验。试验中将这些关键部件逐步组装到光弹体上，前后共测试了16种模型状态，经对比分析，确定了气动性能最优的外形，且该最优外形与数值计算所确定的最优模型一致。随后对该最优气动外形的导弹进行全弹风洞测力试验。试验表明，相较于基准弹，优化后的导弹模型各项气动性能均有所提高，其中，轴向力系数数值减小了3%～4%，纵向焦点位置平均后移3%左右，平衡攻角较基准弹减小1.5°（60%）左右，对质心的俯仰舵效减小了40%左右，滚转舵效减小了35%左右。试验结果与同条件下的数值计算结果吻合较好，同时这也验证了导弹气动优化过程中CFD数值计算方法的合理性。
    Abstract: Many researches show that missiles propelled by ducted solid rocket ramjet is regarded superior at the aspects of firing range, velocity and maneuverability. To improve the unexpected defects of some solid fuel ramjet missiles, such as larger flight drag, poor static stability, larger trimming angle of attack and higher rudder effect, comparative studies of key components to the aerodynamic performance of the missile were fulfilled, a series of significant different models comparing to the basic missile configuration were established based on the aerodynamic characteristics of some components that exercise a major influence on the missile performance. Using the CFD software Fluent, the missile flow fields with different attack angles were simulated numerically, and corresponding axial force coefficient, normal force coefficient and pitching moment coefficient with variety of attack angels were obtained, the pressure distributing trend were analyzed. The results indicated that, in terms of the optimization target, configuration with larger size inlet, smaller wing, rudder surface of edge, sweepback rudder surface and horizontal tail is superior to others. To validate this analysis, an experiment were carried out in the FD-06 hypersonic wind tunnel. The key components were installed on the missile body step by step by building up method. Totally, 16 models were tested, and the test results indicated that the optimal shape showed the consistent with the optimal model obtained by CFD analysis. Comparing to the basic missile, various performances of the optimized model were improved obviously under the studied conditions, the axial force coefficient decreased about 3.0%~4.0%, the longitudinal focus position moved backwards about 3.0% and the balance angle of attack decreased about 1.5°(60%), and the pitching and rolling rudder effect reduced 40% and 35% respectively. Furthermore, CFD results agreed well with the test results, and the reasonableness of CFD numerical methods instead of tunnel test results in the process of aerodynamic optimization were verified.
    • HTML全文
    • 参考文献(20)
  • [1] Hayes C. Aerodynamic characteristics of a series of twin-inlet air-breathing missile configuration. Ⅱ: two-dimensional inlets at supersonic speeds[R]. NASA TM-84559, 1983.
    [2] Xie L R, Guo R W. Experimental investigation of Fixed-geometry two-dimensional mixed-compression supersonic inlet with twin-inlet 90°configuration at venter[J]. Acta Aeronautica et Astronautica Sinica, 2009, 30(6): 1000-1006. (in Chinese)谢旅荣, 郭荣伟. 双下侧定几何二元混压式超声速进气道的风洞试验[J]. 航空学报, 2009, 30(6): 1000-1006.
    [3] Dulikravich G S. Aerodynamics shape design and optimization[R]. AIAA 91-0476, 1991.
    [4] Li M, Song W Y, He W. Design method two-dimensional hypersonic forebody/inlet of mixed compression[J]. Journal of Propulsion Technology, 2004, 19(4): 459-465. (in Chinese)黎明, 宋文艳, 贺伟. 高超声速二维混压式前体/进气道设计方法研究[J]. 航空动力学报, 2004, 19(4): 459-465.
    [5] Zhang X J, Liang D W, Li W, et al. Study of design method of typical two-dimensional hypersonic inlet[J]. Journal of Aerospace Power, 2007, 22(8): 1290-1296. (in Chinese)张晓嘉, 梁德旺, 李博, 等. 典型二元高超声速进气道设计方法研究[J]. 航空动力学报, 2007, 22(8): 1290-1296.
    [6] Hagenmaier M A, Davis D L. Scramjet component optimization using CFD and design of experiments[R]. AIAA 2002-0544.
    [7] Liu J M, Hou Z Q, Song G B, et al. Optimization design and aerodynamic characteristic analysis of waverider based hypersonic cruise missile configuration[J]. Acta Aerodynamica Sinica, 2011, 29(1): 118-122. (in Chinese)刘济民, 侯志强, 宋贵宝, 等. 高超声速巡航导弹乘波构型优化设计与性能分析[J]. 空气动力学学报, 2011, 29(1): 118-122.
    [8] Liu J M, Hou Z Q, Song G B, et al. Conceptual design and optimization for forebody/inlet of hypersonic cruise missiles[J]. Acta Aerodynamica Sinica, 2013, 31(3): 321-325. (in Chinese)刘济民, 侯志强, 宋贵宝, 等. 高超声速巡航导弹前体/进气道概念设计与优化[J]. 空气动力学学报, 2013, 31(3): 321-325.
    [9] Xu D J, Sun B, Xu X, et al. Integrated design and optimization method for scramjet[J]. Journal of Propulsion Technology, 2002, 23(5): 360-362. (in Chinese)徐大军, 孙冰, 徐旭, 等. 超燃冲压发动机一体化设计与优化方法研究[J]. 推进技术, 2002, 23(5): 360-362.
    [10] Luo W C, Chen X Q, Luo S B, et al. Genetic algorithm applied to integral design optimization of missile propelled by solid rocket ramjet[J]. Journal of Solid Rocket Technology, 2002, 25(3): 1-4. (in Chinese)罗文彩, 陈小前, 罗世彬, 等. 固体火箭冲压发动机导弹一体化遗传算法优化设计[J]. 固体火箭技术, 2002, 25(3): 1-4.
    [11] Chang Y X, Gao Z H. Applicability analysis of genetic algorithms using in aerodynamic optimization[J]. Acta Aerodynamica Sinica, 2009, 27(2): 167-172. (in Chinese)常彦鑫, 高正红. 遗传算法在气动优化问题中的适应性分析[J]. 空气动力学学报, 2009, 27(2): 167-172.
    [12] Yamamoto K, Inoue O. Applications of genetic algorithms to aerodynamic shape optimization[R]. AIAA 95-1650, 1995.
    [13] Cook A M, Crossley W. Parallel genetic algorithm approaches to smart actuator placement for aircraft flight control[R]. AIAA 2000-1582. 41st AIAA/ASME/AHS/ASC Structures, Structural Dynamics and Materials Conference and Exhibit. Atlanta, GA, U. S. A., 2000.
    [14] Besnard E, Cordierlallouet N, Kural O, et al. Design/optimization with advanced simulated annealing[R]. AIAA 99-0186, 1999.
    [15] Wang D, Bai J Q, Zhu J, et al. Fast optimization design with multi-requirements based on the analysis of partial correlation[J]. Acta Aerodynamica Sinica, 2014, 32(2): 146-153. (in Chinese)王丹, 白俊强, 朱军, 等. 基于偏相关性分析的多设计要求快速优化设计方法[J]. 空气动力学学报, 2014, 32(2): 146-153. doi: 10. 7638/kqdlxxb-2012. 0078
    [16] Gong C L, Gu Z F, Zhao J S, et al. Design and optimization of multi-stage solid launch rocket based on integrated stage concept[J]. Journal of Solid Rocket Technology, 2009, 32(1): 1-5. (in Chinese)龚春林, 顾振芳, 赵吉松, 等. 基于整体级概念的多级固体运载火箭设计与优化[J]. 固体火箭技术, 2009, 32(1): 1-5.
    [17] Gu L X, Gong C L. A faster and better optimization of integrated design of integral rocket-ramjet missile with GACOM[J]. Journal of Northwestern Polytechnical University, 2004, 22(3): 317-320. (in Chinese)谷良贤, 龚春林. 基于遗传算法的组合优化方法在整体式冲压发动机导弹一体化设计中的应用[J]. 西北工业大学学报, 2004, 22(3): 317-320.
    [18] Zhao J M, Xia Z X, Guo J, et al. Integral design optimization for missiles/solid rocket ramjets based on all schema genetic algorithm[J]. Journal of Solid Rocket Technology, 2005, 28(1): 1-4. (in Chinese)赵建民, 夏志勋, 郭建, 等. 基于全模式遗传算法的导弹/固体冲压发动机一体化设计[J]. 固体火箭技术, 2005, 28(1): 1-4.
    [19] Jiang N, Wang Y W, Ling W H, et al. Integration performance analysis of typical arrangement inlet/missile[J]. Journal of Propulsion Technology, 2011, 32(4): 451-454. (in Chinese)蒋妮, 王永卫, 凌文辉, 等. 典型布局的进气道/导弹一体化性能分析[J]. 推进技术, 2011, 32(4): 451-454.
    [20] Li X P, Yang M. Numerical study of inlet configuration effects on aerodynamic performance for air-breathing missiles[J]. Science Technology and Enginering, 2010, 10(35): 8747-8751. (in Chinese)李雪萍, 杨茂. 进气道对导弹气动性能影响的数值研究[J]. 科学技术与工程, 2010, 10(35): 8747-8751.
